New 2025 PJ Trailers Dump 77x12 Stock# 249406

Empty weigh t3166

GVWR 9990

Payload 6824

2 - 5200# Dexter

E-Z Lube - 1/2 Cambered

ST225/75R/15 LRD

Standard Equipment

• Coupler: 2 5/16" Forged Adjustable 5/Position
• Jack: 7000# Drop Leg
• Fenders: HD Diamond Plate Straight
• Floor: 12 GA Sheet Metal
• Width: 77" Inside Box
• Brake: Electric All Wheel
• Break Away Unit w/Charger
• Primed & Painted Underside
• Dual Swing Out Doors
• Spare Rack
• Sealed Flush Mount LED Lights
• Wiring Harness
• Lockable Battery/Pump Box
• Ramps Hangers on Side (Ramps Option)
• 5/8" D-Rings in Box (4)
• Deep Cycle 12V Marine Battery w/110V-5 Amp Charger
• Crank Style Roll Tarp

Frame Structure

• Frame: 5" Channel
• Sides: 24" Tall 12 GA
• Tongue: 5" Channel Wrap
• Uprights: 24" OC
• Dump Body Frame: 5x3x1/4 Angle
• Crossmembers: 3" Channel 16" OC
• Tarp Bracket & Tie Downs
•
• Dump Components:
• Hoist: Scissor Lift
• Power Up/Power Down
• Control: Pistol Grip w/10' Cord
• Safety Prop
• Caulked Seams on Dump Body
